| Principle Specifications |
| L.O.A |
26'-2 |
7.98m |
| LWL |
22'-11 |
6.00m |
| Beam |
9'-10 |
3.00m |
| Draft Fin |
4'-10 |
1.47m |
| Draft Wing |
3'-5 |
1.04m |
| Ballast Fin |
1900 lbs |
861kg |
| Ballast Wing |
1750 lbs |
793kg |
| Displacement Fin |
5250 lbs |
2378kg |
| Displacement Wing |
5100 lbs |
2310kg |
| Fresh Water Tank |
18 gallons |
68 liters |
| Waste Holding Tank |
12 gallons |
45 liters |
| Water Heater Tank |
6 gallons |
23 liters |
| Fuel Tank |
14 gallons |
53 liters |
| Sail Area |
295 sq. ft. |
27.41kg |
| I |
32.90' |
10.03m |
| J |
8.70' |
2.65m |
| P |
27.60' |
8.41m |
| E |
11.00' |
3.35m |
| * All measurements are approximate |
|
|
|
|
|
|
